IP67 Stainless Steel Inductive Sensors NPN NC Quasi Flush 2mm LED Display

Name: IP67 Stainless Steel Inductive Sensors NPN NC Quasi Flush 2mm LED Display
Brand: KRONZ
Price: 1 USD

IP67 Stainless Steel Inductive Sensors NPN NC Quasi Flush 2mm LED Display Manufactures

Brand Name : KRONZ

Model Number : IS2-M8NC60-S0B/D

Certification : CE

Place of Origin : Guangdong, China

MOQ : 10 pieces

Price : Negotiable

Payment Terms : T/T,Western Union,MoneyGram

Supply Ability : 100000 pieces per month

Delivery Time : 5-8 working days

Packaging Details : Polybag packing

Installation Type : Quasi-flush

Output : NPN NC

Connection Type : M8 Connector

Max. load current : 100mA

No Load Current : <10mA（24V）

Voltage Drop : <2.0v

Protection Grade : IP67

Ambient Temperature : -25℃ to +70℃

Sensing Surface Material : POM

Contact Now

This stainless steel inductive proximity sensor provides reliable, non-contact detection of ferrous and non-ferrous metals (including stainless steel) in demanding industrial applications. Its corrosion-resistant 316L stainless steel housing ensures durability in wet, humid, or chemically aggressive environments.

Features:

■ Installation type: Quasi-flush
■ Sensing range Sn: 2mm
■ Output function: NPN,NC
■ Supply voltage: 10-30VDC
■ Connection type: M8 connector
■ Housing material: Stainless steel

Technical Data

Installation Type	Quasi-flush
Detection Distance	2mm
LED Display	Yes
Working Voltage	10-30VDC
No Load Current	<10mA (24V)
Max. load current	100mA
Voltage drop	<2.0v
Switching frequency	3kHZ
Tolerance(Sr)	＜10%
Leakage current	＜0.01mA
Response time	0.1ms
Temperature drift	＜10%sr
Switch hysteresis	<15%sr
Repeatability	<1.0%sr
Short-circuit protection/Reverse polarity protection	Yes
Overload current protection	220mA
Protection grade	IP67
Ambient temperature	-25℃ to +70℃
Sensing surface material	POM
Connection type	M8 connector

Dimensional Drawing

IP67 Stainless Steel Inductive Sensors NPN NC Quasi Flush 2mm LED Display

Wiring Diagram

IP67 Stainless Steel Inductive Sensors NPN NC Quasi Flush 2mm LED Display
